Pallet Mould

Specialized in design and production of plastic-injection mould.

Mould Name: Pallet mould

Mould Size: 960*960*673mm

Product description: PP/PE

Mould cavity: 1 cavity

Suitable machine: 800T

Mould steel: Core and Cavity as a insert Germany Thyssen 1.2738, Prehard HRC33-38;

Sliders steel: Germany Thyssen 1.2738, Prehard HRC33-38;

Mould Base S50C;

HASCO Mould standard spare parts

Mould life: 500,000 shots

Mould Injection system: YUDO 4 Open nozzles +manifold

Mould Ejection system: ejector pins

Mould running: Automatic

Mould cycle time: 60 seconds

Delivery time: 60 days for T1 samples

Pallet-Mould-30
Pallet-Mould-30
Pallet-Mould-31
Pallet-Mould-31
Pallet-Mould-32
Pallet-Mould-32
